Concrete Diamond Chainsaw

CS11

Description

CS11 Concrete Diamond Chainsaw from AGP. 330mm concrete chainsaw with 2600W universal motor and up to 300mm plunge cutting depth. Excellent for precise corner cut outs with no over cuts. Also ideal for cutting concrete pipes.

  • 2600W electric motor
  • W300mm depth of cut
  • Electronic protection for over / under voltage – fitted with RCD unit
  • Soft start with LED load feedback indicator
  • Electronic and thermal overload protection
  • Waterproof and dustproof hall effect switch
  • Built-in spirit levels for accurate alignment
  • Bumper Spike for increased leverage
  • Splash flap for operator protection
  • Cord length of 2.5m – Hose length of 0.7m
Use me for…

Excellent for precise corner cut outs with no over cuts & cutting concrete pipes.

CS11 Electric Chainsaw

Concrete Diamond Chainsaw
  • Soft start with LED load feedback indicator
  • Electronic protection for over / under voltage
  • Integrated water feed
  • Electric and thermal overload protection
  • Bumper spike for increased leverage
  • Splash flap for operator protection
  • Dual spirit levels
  • Cord length of 2.5m - Hose length of 0.7m

Sizing Options

ModelCS11
Power Input2600W
110V: 2600W
Voltage220-240V~ 50/60Hz or 110-120V~ 50/60Hz
No Load Min¯¹10000
Linear Speed20.65 m/s
Guide Bar Length382 mm(15‘’)
Diamond Chain25 links
Max. Cutting Depth300 mm (11.8″)
Protection ClassClass I, (220V models with PRCD / GFCI)
Dimensions (LxWxH)630 mm (930 mm with guide bar) x 215 mm x 280 mm
Net Weight8.1 kg (17.85 Lbs), 9.04 kg (19.92 Lbs) with guide bar & chain)
Vibration m/s24.3
Noise Level db(A)100.5



ACCESSORIES FOR CS11 DIAMOND CHAINSAW

DescriptionPart No.
Diamond Chain305-00035-000-006
Sprocket305-00403-000-001
Guide Bar305-00404-000-001
